Product

PZS series

With swivelling eye

PZS series ,

Product
Description

Available as standard with swivelling towing eye Ø 40 mm (DIN 74054-40 A) and towing eye Ø 50 mm (DIN 74053-50 A). In all standard versions, the bearing eyes have plastic bushes. Other dimensions and towing eyes are available on request.

Choose variant

PZS - dimensions_Ny-01

                                                       SINGLE AXLE

Max axle load (t)

DZ min. (mm)
         10        600

                                                        TWO AXLES

Max axle load (t)

RA max. (mm)

DZ min. (mm)

PZS - dimensions_Ny-01

                                                       SINGLE AXLE

Max axle load (t)

DZ min. (mm)
         12        600

                                                        TWO AXLES

Max axle load (t)

RA max. (mm)

DZ min. (mm)

PZS - dimensions_Ny-01

                                                       SINGLE AXLE

Max axle load (t)

DZ min. (mm)


                                                        TWO AXLES

Max axle load (t)

RA max. (mm)

DZ min. (mm)
            20
